Konstruktionstipps: Innovative Lüfterkomponenten durch Tiefziehen (Eng)

Is the manufacturing of fan components a part of your business? Are you constantly seeking better product development and more optimal products? We have prepared a presentation for you, which provides tips on the efficient design and implementation of fan parts.

Topics include:

• Optimal and repeatable level tip clearance
• Light and robust structure
• Various functionalities and shapes – combined into a single part
• Accuracy & Simplicity

New applications require new fan housing innovations, and, in many times, it is not possible to use standard components; thus, there is need for small volume solutions with innovative design. Also, standard fan solutions are not optimal for all end user solutions. Custom-designed fans and fan housings enable maximum efficiency, optimal airflow, and low noise levels.

We at Meconet want to help you to solve the challenge of designing a perfect fan product. With our capabilities and methods, we could support you in achieving:

• Optimal and repeatable level tip clearance
• Light and robust structure
• Optimized inlet/outlet shape according to your flow simulation
• Various functionalities combined in one part
• Minimum number of parts in assembly
• Minimal welding and unwanted assembly work
• Sophisticated look and high-quality feel

We can also offer you complete fan housing simulation already at design-phase and there are many different benefits to it:

1. Error minimization

2. Cost savings

3. Improvement in product quality:

4. Faster market entry

5. Promotion of innovations

6. Reduction of environmental impact
